DJI RS 3 Pro Gimbal Stabilizer Combo
Features
- Lightweight Design with 10 lb Payload
- Combo Includes Phone Holder, Focus Motor
- Multiple Camera Control Cables
- Advanced 1.8" OLED Touchscreen
- Instant Mode Switching, Auto-Lock Axes
Related Products
Description
The DJI RS 3 Pro is more than just a gimbal: it is an advanced camera expansion platform that empowers solo videographers and provides coordinated solutions for professional crews.
The new extended carbon fibre axis arms allow you to balance huge payloads while its LiDAR system introduces autofocus to manual lenses and the DJI RS SDK empowers third-party hardware manufacturers to create new, customised solutions.
Every detail of DJI RS 3 Pro has been meticulously designed so that nothing is out of reach.
This combo also includes the Ronin Image Transmitter, Focus Motor (2022), Lower Quick-Release Plate (Extended), and other accessories.
Key Features:
- 1.5 kg (including gimbal, battery grip, and dual-layered quick-release plates)
- 4.5kg max tested payload
- Automated axis locks
- Extended carbon fibre axis arms
- 3rd-Gen DJI RS Stabilisation Algorithm
- Gimbal mode switch
- Bluetooth shutter
- 1.8'' OLED full-colour touchscreen
- Supports LiDAR focusing system (multi-point)
- Compatible with DJI Transmission, DJI Ronin Image Transmitter
- Detachable battery
- Supports expansion with vehicle mount, Steadicam, slider, cable cam, and jib
- Includes dual-layered quick-release plates; the Combo additionally includes Lower Quick-Release Plate (Extended)
Automated Axis Locks Get You Ready Instantly
Automated Axis Locks get the gimbal ready to work or sleep instantly, making company move and gear storage significantly more efficient.
Increased Payload Capability, Stiffer Gimbal
Extended Carbon Fibre Axis Arms allow more balancing space and are constructed from layered sheets of uncut carbon fibre to improve stiffness and reduce weight.
4.5kg Tested Payload
With a larger balancing space, RS 3 Pro remains just 1.5 kg, while its load capacity is 4.5 kg to meet various shooting needs.
Advanced LiDAR Focusing
The LiDAR focusing system makes focusing easier and enables autofocus on manual lenses when paired with the focus motor. It also supports ActiveTrack Pro for advanced tracking.
Long-Range O3 Pro Video Transmission
Supports 6km video and audio transmission with ultra-low latency, impressive stability, and extensive coordinated control features.
Specifications
Grip Design | Single Handgrip |
Gimbal | |
Load Capacity | 4.5 kg |
Number of Axes | 3-Axis (Pitch, Roll, Yaw) |
Rotation Range | Yaw (Pan): 360° Pitch (Tilt): -112 to 214° Roll: -95 to 240° |
Follow Speed | Pan: 360°/s Tilt: 360°/s Roll: 360°/s |
Compatibility | |
Camera Control | On Compatible Models |
Camera Mounting Screw | 1 x 1/4"-20 Male |
Connectivity | |
Inputs/Outputs | 3 x USB Type-C (Control) Output 1 x USB Type-C (Power) |
Wireless Frequency | 2.4 GHz (2.4 - 2.484) |
Wireless Protocol | Bluetooth 5.0 |
Battery | |
Battery Type | 1 x Built-In |
Battery Capacity | 1950 mAh / 30 Wh |
Battery Runtime | 12 Hours |
Battery Charging Time | 1.5 Hours |
Battery Chemistry | Lithium-Ion Polymer (LiPo) |
Voltage | 15.4 VDC |
Environmental | |
Operating Temperature | -20 to 45°C |
General | |
Display Type | Fixed Touchscreen OLED |
Materials | Carbon Fibre |
Mounting | 1 x 1/4"-20 Female 1 x Cold Shoe Mount |
Dimensions | 415 x 218 x 195 mm 276 x 268 x 68 mm (Folded) |
Weight | 1497 g |
In The Box
- DJI RS3 Pro Gimbal Stabilizer
- Ronin Image Transmitter
- BG30 Grip
- Lens-Fastening Support (Extended)
- Extended Grip/Tripod (Metal)
- Briefcase Handle
- Quick-Release Plate (Arca-Swiss/Manfrotto)
- Lower Quick-Release Plate (Extended)
- Phone Holder
- Focus Motor (2022)
- Focus Motor Rod Mount Kit Combo
- Focus Gear Strip
- Lens-Fastening Strap
- 2 x Hook-and-Loop Strap
- USB-C Power Cable (20 cm)
- Mini-HDMI to HDMI Cable (20 cm)
- Mini-HDMI to Mini-HDMI Cable (20 cm)
- Mini-HDMI to Micro-HDMI Cable (20 cm)
- 2 x Multi-Camera Control Cable (USB-C, 30 cm)
- USB-C Charging Cable (40 cm)
- Screw Kit
- Carrying Case
Reviews
(no ratings yet)Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: DJI RS 3 Pro Gimbal Stabilizer Combo
- Manufacturer: DJI
- Model: RS 3 Pro
- SKU: CP.RN.00000218.01
- RM Product #: 97119
- Series/Compatibility: Ronin
