| Camera |
|
| Image Sensor |
1/2.7"6Megapixel progressive CMOS |
| Max. Resolution |
3072(H) × 2048(V) |
| ROM |
128 MB |
| RAM |
512 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s-1/100,000 s |
| Min. Illumination |
0.005 Lux @F1.6 |
| S/N Ratio |
> 56 dB |
| Illumination Distance |
50 m |
| Illuminator On/Off Control |
Auto/Manual |
| Illuminator Number |
2 (IR LED) |
| Pan/Tilt/Rotation Range |
Pan: 0°-360°
Tilt: 0°-78°
Rotation: 0°-360° |
| Lens |
|
| Lens Type |
Fixed-focal |
| Mount Type |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Max. Aperture |
F1.6 |
| Field of View |
2.8 mm: Horizontal 99° × Vertical 72° × Diagonal 131°, 3.6 mm: Horizontal 80° × Vertical 58° × Diagonal 106° |
| Iris Type |
Fixed |
| Close Focus Distance |
2.8 mm: 1.4 m
3.6 mm: 2.4 m |
| Electronic Shutter Speed |
Auto/Manual 1/3 s-1/100,000 s |
| Video |
|
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec |
Smart H.265+/ Smart H.264+ |
| Stream Capability |
3 streams |
| Video Frame Rate |
Main stream (3072 × 2048@1-25/30 fps)
Sub stream (704 × 576@1-25 fps/ 704 × 480@1-30 fps)
Third stream (1920 × 1080@1-25/30 fps) |
| Resolution |
6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 3 kbps-8192 kbps
H.265: 3 kbps-8192 kbps |
| Day/Night |
Auto (ICR)/Colour/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation(SSA) |
Yes |
| White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower.) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Audio |
|
| Built-in MIC |
Yes |
| Audio Compression |
G.711a; G.711Mu; G726 |
| Network |
|
| Network |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec |
| User/Host |
20 (Total bandwidth: 72 M) |
| Storage |
FTP; SFTP; Micro SD card (support max. 256 G); NAS |
| Browser |
IE: IE8; IE9; IE11
Chrome
Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Phone |
IOS; Android |
| Power |
|
| Power Supply |
12V DC/PoE (802.3af) |
| Power Consumption |
Basic power consumption: 2.8W (12V DC); 3.5W (PoE) |
| Max. power consumption |
(WDR + H.265 + IR LED intensity): 6.7W (12V DC); 7.5W (PoE) |
| Environment |
|
| Operating Conditions |
-40°C to +60°C /Less than 95% RH |
| Storage Conditions |
-40°C to +60°C |
| Protection Grade |
IP67 |
| Structure |
|
| Casing |
Metal |
| Dimensions |
106 mm × 93.6 mm |
| Net Weight |
0.55kg |
| Gross Weight |
0.71kg |
