| Module |
|
| USB |
Up to five USB devices |
| Connectivity |
Ethernet and Wi-Fi (built into Cube)
Up to four iOS devices |
| Compatibility |
Cube 605/655, 715/755, 805/855 |
| Interfaces |
Controlled through Cube
4x powered USB 2.0 host port |
| Battery |
Internal lithium-ion |
| Power Consumption |
Nominal: 0.5 W, up to 5 W per USB device
Power supplied by Cube |
| Temperature |
Operating: 14 to 122°F (-10 to 50°C)
Storage: -40 to 194°F (-40 to 90°C) |
| Humidity |
Operating: 5% to 95% (non-condensing)
Storage: Maximum 90% |
| Construction |
Milled aluminium (Chassis), regulation-compliant PCB |
| Dimensions |
1 x 3 x .4.7" (24 x 77 x 120 mm) |
| Weight |
7.9 0z (224 g) |
| Encoder |
|
| Video Inputs |
1 x SD/HD-SDI (75 Ohms BNC)
1 x HDMI type A receptacle |
| Channel Bonding |
TeraLink |
| Supported Resolutions |
1080p 23.98/24/25/29.97/30/50/59.94/60
1080i 50/59.94/60
1080psF 23/24/25/29/30
720p 50/59.94/60
576i
480i
480p (for HDMI input only)
576p (for HDMI input only)
Ingests 1080p 50/59/60 |
| Video Compression |
H.264, Baseline, Main, and High Profile |
| Supported Video Bit Rates |
250 kbps to 15 Mbps
15 Mbps (wired), 10 Mbps (Wi-Fi) |
| Test Pattern Generator |
Supports custom test pattern |
| Video Format |
Built-in video scaler and deinterlacer |
| Colour Correction |
CDL/1024 1D LUT (supports 10-bit colour)
33 x 33 x 33 3D LUT (supports 10-bit colour) |
| Network Protocols |
TCP/IP, UDP, HTTP, DHCP, NTP, SSL, IGMP |
| Video Transport Support |
Supported Video Transport Protocols:
RTMP
RTP, RTSP, RTSP over HTTP
MPEG-TS (MPEG-TS is an optional paid licence) |
| Remote Control |
Teradek Core |
| Software Integration |
Ustream, YouTube Live, Facebook, and new Livestream |
| Audio Compression |
AAC-LC, MPEG Layer 2 |
| Audio Input |
Embedded audio input
Analogue line or mic in, adjustable gain |
| Audio Output |
Headphone output |
| Interfaces |
Http: WebUI for configuration and control
Configuration Interfaces:
OLED display with joystick navigation buttons
Feature-rich WebUI for configuration and control |
| Switches |
On/Off and reset switch |
| Recording storage |
SD Card: Full-size |
| Mobile App |
Vuer, Live:Air |
| USB Interface |
Powered USB 2.0 host port |
| Ethernet |
10/100/1000 BASE-T gigabit |
| Wi-Fi |
2.4/5 GHz 802.11 ac/a/b/g/n MiMo |
| Channel Selection |
Auto with three Modes: 2.4 or 5 GHz, Auto 2.4 GHz only, Auto (5 GHz only)
Configurable to specific channels |
| Encryption |
802.1x, 802,11i, WPA2, WPA, and WEP 64/128 TKIP 128-bit AES |
| Power Input |
2-pin connector power input |
| Power Consumption |
Nominal: 8 W, 7 W (no Wi-Fi) |
| Power Input |
Auxiliary: 6-28 VDC |
| Mount |
Can be mounted horizontally or vertically with 1/4"-20 mounting holes |
| Construction |
Milled aluminium |
| Dimensions |
4.75 x 3 x 1.1" [120.7 x 76.2 x 27.9 mm] |
| Weight |
11.6 oz (328.9 g) |
