Audio-Technica ATV-SG1 Camera-Mount Shotgun Microphone

Product #125242 | SKU ATV-SG1 | Audio Technica
Coming Soon ETA to be confirmed
NEW
Our Price $359 AUD
Coming Soon ETA to be confirmed
NEW
- +

Email me when stock arrives

Shipping & Availability
ETA to be confirmed. Deliver to New South Wales for $20.90 Change location
Click & Collect Availability
Sydney Out of stock. ETA to be confirmed
Click & Collect

Features

  • For Videographers and Content Creators
  • Mounts onto DSLR and SLR Cameras
  • 14mm Large-Diaphragm Capsule
  • 100mm Tube for Directional Sound
  • Integrated Shockmount
  • A-T Tech for Resisting Hum/RF Noise

Description

The Audio-Technica ATV-SG1 Camera-Mount Shotgun Microphone is thoughtfully crafted for videographers and content creators who demand professional-caliber audio performance. With its shotgun design, this microphone easily mounts onto your preferred DSLR or SLR camera, delivering a host of advanced features, flexible customization options, and direct headphone monitoring. At its core is a 14mm large-diaphragm capsule, combined with a 100mm highly directional acoustic tube, which allows for precise capture of your intended sound source while effectively minimizing background noise. Sound quality is further enhanced by an integrated shockmount that mitigates handling and vibration noise, and proprietary A-T noise-immunity technology ensures strong resistance to hum and RF interference from devices like smartphones and other electronics.

Flexible Mounting and Orientation

A standout feature is the 12-sided shoe mounting plate, which enables rotation in 30° increments, granting exceptional flexibility for horizontal positioning and achieving precise orientation. This adaptability ensures you can always aim the microphone exactly where you need for optimal audio capture.

Onboard Controls and Redundancy

The microphone offers easy-to-access onboard controls, including a low-cut filter and gain adjustment, so you can shape your recording characteristics to match any scenario. For added security, the safety track option splits the audio signal, allowing for a redundant, clip-free backup recording—a valuable asset during unpredictable or high-stakes shoots.

Power and Accessories

Powering the ATV-SG1 is simple and dependable, thanks to USB-A to USB-C recharging, with a single charge providing up to 24 hours of continuous use. For outdoor shooting, a supplied windjammer helps to tame extreme wind noise, ensuring your recordings remain clear and intelligible even in challenging environments.

Specifications

Microphone
Microphone Type 1/8" / 3.5 mm Plug-In Mount / Shotgun
Polar Pattern Lobar
Element Type Condenser
Sound Field Stereo
Diaphragm 0.6" / 14 mm
Orientation End Address
Controls Gain/Sensitivity, Headphone Volume, Low Cut/HPF
Filter & AEQ Low-Cut Filter: 160 Hz, 24 dB/Octave
Circuitry Tube/Solid-State Hybrid
Performance
Frequency Response 60 Hz to 20 kHz
Maximum SPL 126 dB (1 kHz, THD 3%, Maximum Gain)
132 dB (1 kHz, THD 3%, Minimum Gain)
Sensitivity -28 dBV (Maximum Gain)
-35 dBV (Gain Setting: 5)
Dynamic Range 109 dB (1 kHz, THD 3%, Maximum Gain)
Equivalent Noise Level 77 dB (1 kHz at 1 Pa, A-Weighted, Maximum Gain)
Connectivity
Analogue Output Connector 1x 1/8" / 3.5 mm TRS Female
Inputs 1x 1/8" / 3.5 mm TRS (on Mic)
Cable Length 20" / 50.8 cm
Power
Power Sources Plug-In Power
Operating Voltage No Power Required
Battery Type 1x Built-In Rechargeable (Included)
Physical
Colour Black
Mounting Thread Size Included Mount Has No Threading
Dimensions ø: 1.4 x H: 3.2L: 5" / ø: 35.6 x H: 81.3L: 127 mm
Weight 5.5 oz / 156 g

In The Box

  • Audio-Technica ATV-SG1 Camera-Mount Shotgun Microphone
  • Coiled Cable (20")
  • 2 x 3.5mm Stereo Adapter
  • USB-A to USB-C Charging Cable
  • Windjammer

Reviews

0.0 (no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review

Details

  • Product: Audio-Technica ATV-SG1 Camera-Mount Shotgun Microphone
  • Manufacturer: Audio Technica
  • Model: ATV-SG1
  • SKU: ATV-SG1
  • RM Product #: 125242
  • Warranty: 1 year manufacturer warranty on all Audio Technica products. 5 year limited warranty on all Audio Technica Wired Microphones.
