| Key Specs |
|
| Max I/O Capacity |
48x Input / 28x Output |
| Number of Analogue Input Channels |
24 (24 Mono / 0 Stereo) |
| Number of Mic Preamps |
24 |
| Number of Analogue Output Channels |
8 |
| Faders & Level Adjustment |
No |
| Analogue Inputs |
8x XLR 3-Pin Balanced Mic/Line Input
8x 1/4" TRS Aux Input |
| Analogue Outputs |
8x XLR 3-Pin Main/Bus Output
8x 1/4" TRS Stereo Aux/Headphone Output
2x 1/4" TRS Unbalanced Stereo Headphone Output
5x 1/4" TRS Unbalanced Stereo Headphone Output |
| Digital I/O |
2x RJ45 Ethernet (Control, 1 Gb/s)
3x RJ45 AES50 (I/O)
1x XLR AES3 Input (I/O)
1x XLR AES3 Output
1x XLR Input/Output (I/O) |
| USB I/O |
1x USB-B 2.0 (Audio Playback, Control, Multitrack Record) |
| Wireless |
No |
| Rack Mountable |
Yes |
| Mixer |
|
| Max I/O Capacity |
48x Input / 28x Output |
| Number of Analogue Input Channels |
24 (24 Mono / 0 Stereo) |
| Number of Mic Preamps |
24 |
| Number of Analogue Output Channels |
8 |
| Mix Routing |
28x Stereo Bus |
| Groups |
No |
| Presets |
No |
| Display |
Main Display:
10.1" LCD Touchscreen (Daylight-Viewable)
Channel Display:
2.4" LCD |
| Faders & Level Adjustment |
No |
| Metres |
2x 18-Segment LED |
| Signal Processing |
|
| Gain/Trim Range |
Mic:
0 dB to +72 dB |
| Input Polarity |
Normal/Reverse |
| Dynamic Processing |
Input Channels:
Compressor, Limiter, Soft Limiter, Gate |
| AEQ |
4-Band AEQ |
| Graphic AEQ |
Yes |
| Solo/Mute |
Solo, Mute per Input Channel
Mute per Master |
| Audio Delay |
Yes |
| Automatic Mic Mixing |
No |
| Digital Audio |
|
| Sample Rates |
Up to 192 kHz |
| Bit Depth |
AD/DA Conversion:
24-Bit |
| Performance |
|
| Frequency Response |
10 Hz to 20 kHz +0/-1 dB (at 48 kHz) |
| Max Input Level |
XLR Mic Input:
+21 dBu |
| Analogue Dynamic Range |
111 dB |
| Headphone Output Power |
500 mW per Channel into 75 Ohms |
| I/O Impedance |
XLR Mic Input:
1 Kilohms (Unbalanced)
2 Kilohms (Balanced)
XLR Output:
75 Ohms (Balanced/Unbalanced)
Line Output:
150 Ohms (Unbalanced)
300 Ohms (Balanced) |
| Noise Floor |
-95 dBu A-Weighted |
| THD+N |
Mic Input to Analogue Output:
0.006% at +40 dB Gain (+20 dBu, Output)
0.004% at Unity Gain (0 dBu, Output) |
| Signal Generator |
No |
| Connectivity |
|
| Analogue Inputs |
8x XLR 3-Pin Balanced Mic/Line Input
8x 1/4" TRS Aux Input |
| Analogue Outputs |
8x XLR 3-Pin Main/Bus Output
8x 1/4" TRS Stereo Aux/Headphone Output
2x 1/4" TRS Unbalanced Stereo Headphone Output
5x 1/4" TRS Unbalanced Stereo Headphone Output |
| Phantom Power |
+48 V (Selectable on Individual Inputs) |
| Digital I/O |
2x RJ45 Ethernet (Control, 1 Gb/s)
3x RJ45 AES50 (I/O)
1x XLR AES3 Input (I/O)
1x XLR AES3 Output
1x XLR Input/Output (I/O) |
| MIDI I/O |
1x MIDI 5-Pin In
1x MIDI 5-Pin Out |
| USB I/O |
1x USB-B 2.0 (Audio Playback, Control, Multitrack Record) |
| USB I/O Capacity |
48x Input / 48x Output |
| Other I/O |
2x 1/4" TRS GPIO In/Out |
| Expansion Ports |
No |
| Wireless |
No |
| External Display I/O |
No |
| Max Multitrack Recording |
64 Tracks |
| Media Support |
SD, SDHC |
| Compatibility |
|
| Mobile Device Compatibility |
iPad
Android Tablet |
| Power |
|
| Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Physical |
|
| Rack Mountable |
Yes |
| Rackmount Size |
4 RU (with Included Hardware) |
| Dimensions |
19.1 x 12.8 x 7.2" / 48.5 x 32.5 x 18.3 cm |
| Weight |
20.9 lb / 9.5 kg |
