The Blackmagic Design ATEM Mini Extreme ISO G2 Switcher is a cutting-edge 8-input live production switcher designed for live streaming with an integrated control panel and advanced broadcast capabilities. Not only can you live stream using RTMP protocols, but you can also output your program as if it were a webcam via USB. The latest updates bring a totally revamped keyboard with numerous knob controls, spacious NKK red/green source select buttons, a hardware fader, a CFexpress slot, and Thunderbolt port for recording, as well as a more user-friendly button layout.
Blackmagic Design ATEM Mini Extreme ISO G2 Switcher
Coming Soon
Estimated to ship June
Our Price
$3,079
AUD
Coming Soon
Estimated to ship June
Email me when stock arrives
Shipping & Availability
Estimated to ship June.
Deliver to
New South Wales
for $5.90
Change location
Click & Collect Availability
Sydney
Out of stock.
Estimated to ship June
Click & Collect
Features
- 8-Channel HDMI Live Streaming Switcher
- All-New Design, Supports up to 1080p60
- 1G & 10G Ethernet Ports, CFexpress Slot
- 3 Independently Assignable HDMI Outputs
- 26-Input, 2-Channel Audio Mixer
- Input Frame Rate & Format Convertor
Description
Specifications
| Available M/E Layers | 9 M/E |
| Effect Types | 2x DVE 4x Luma Key 4x Chroma Key |
| Graphics Memory | 20 Images |
| Downstream Keys | 2x Chroma, Luma, DVE |
| Generators | 5x Pattern 2x Colour |
| Audio Mixing | 2-Channel Mixing |
| Processing | |
| Switching Type | Pushbutton, Software |
| Processing Resolution | 1080p |
| Input | |
| Number of Video Input Sources | 8 |
| Video Inputs | 8x HDMI |
| Input Video Format | HDMI (10-Bit 4:2:2 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps |
| Audio Inputs | 2x XLR 3-Pin Mono Analogue Female 1x BNC Female |
| Input Audio Format | Analogue |
| Embedded Audio Input | HDMI: 2-Channel (per Input) |
| Output | |
| Video Output Channels | 2 |
| Video Outputs | 3x HDMI Female |
| Output Video Format | HDMI (10-Bit 4:2:2 YUV) 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps |
| Audio Outputs | 1x 1/4" TRS Stereo Analogue Female |
| Embedded Audio Output | HDMI: 2-Channel |
| Multiview Output | 16-Way Multiview via HDMI |
| Connectivity | |
| Other I/O | 2x RJ45 LAN Input/Output 2x USB-C Output 1x Thunderbolt 3 Output |
| HDCP Support | No |
| IP Video | H.264: 1920 x 1080 Encoding |
| Transport Protocols | RTMP |
| Simultaneous Streams | 1 Streams |
| Recording Modes | 1920 x 1080p up to 60 fps (MP4) |
| Hardware | |
| OS Compatibility | macOS 14 or Later / Windows 10 or Later |
| Processor | Not Specified by Manufacturer |
| Wi-Fi | No |
| Bluetooth | No |
| Power I/O | 1x Barrel (12 VDC ) Input |
| General | |
| Operating Conditions | 41 to 104°F / 5 to 40°C up to 70% Humidity |
| Storage Conditions | 14 to 140°F / -10 to 60°C |
| Dimensions | 16.3 x 7.35 x 1.97" / 41.4 x 18.67 x 5 cm |
| Weight | 4.09 lb / 1.86 kg |
In The Box
- Blackmagic Design ATEM Mini Extreme ISO G2 Switcher
- 12 VDC Power Supply
Reviews
(no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: Blackmagic Design ATEM Mini Extreme ISO G2 Switcher
- Manufacturer: Blackmagic
- Model: SWATEMMINICEXTISOG2
- SKU: SWATEMMINICEXTISOG2
- RM Product #: 121057
