The Blackmagic Design UltraStudio Mini Monitor 12G is an output-only device that enables playback via 12G-SDI and HDMI in SD, HD, and Ultra HD. It is an ideal solution for monitoring playback from widely used editing software. Dual 12G-SDI outputs support fill and key for broadcast graphics, with automatic conversion of the alpha channel in graphics into a key output.
Blackmagic Design UltraStudio Mini Monitor 12G
In Stock with Supplier Usually ships in 2 - 3 working days
Our Price
$589
AUD
In Stock with Supplier Usually ships in 2 - 3 working days
Email me when stock arrives
Shipping & Availability
Usually ships in 2 - 3 working days.
Deliver to
New South Wales
for $4.90
Change location
Click & Collect Availability
Sydney
Out of stock.
Pickup in
2 - 3 working days
Click & Collect
Features
- 12G-SDI & HDMI Video Playback
- Outputs Footage from Computer to Monitor
- Thunderbolt 4, SDI & HDMI Connectors
- Supports up to UHD 4K60 Resolutions
- Supports Multiple Video Codecs
- Includes Media Express & Other Software
Description
Specifications
| Inputs/Outputs | |
| System Connection | USB-C (Thunderbolt 4) |
| Video I/O | Output 2x BNC (12G-SDI) Female 1x BNC (12G-SDI) Female (Fill) 1x BNC (12G-SDI) Female (Key) 1x HDMI 2.0 Female |
| Audio I/O | No |
| Format Support | |
| Video Resolution | BNC Input/Output (8-Bit 4:2:2 YUV) 1920 x 1080 up to 60 fps |
| Audio Format | Unspecified Digital Signal Input/Output: 48 kHz / 24-Bit |
| Embedded Audio | HDMI: 8-Channel |
| Standards | |
| Broadcast System Compatibility | NTSC, PAL |
| Hardware | |
| OS Compatibility | macOS 26 Windows 10 to 11 (64-Bit Only) Linux |
| Power | |
| Power Consumption | 15 W |
| General | |
| Operating Conditions | 32 to 104°F / 0 to 40°C up to 90% Humidity |
| Storage Conditions | -4 to 113°F / -20 to 45°C up to 90% Humidity |
| Dimensions | 5.83 x 2.6 x 1" / 148.08 x 66 x 25.4 mm |
| Weight | 8.11 oz / 230 g |
In The Box
- Blackmagic Design UltraStudio Mini Monitor 12G
Reviews
(no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: Blackmagic Design UltraStudio Mini Monitor 12G
- Manufacturer: Blackmagic
- Model: Mini Monitor 12G
- SKU: BDLKULSDZMINMON12G
- RM Product #: 127042
