Blackmagic Video Assist 3G 5" Portable Monitor

Product #74441 | SKU BMD-HYPERD/AVIDA03/5 | Blackmagic
| Read Reviews (1)
In Stock with Supplier Usually ships in 2 - 3 working days what does this mean?
Blackmagic Video Assist 3G 5" Portable Monitor
SALE
Sale Price $490.10 AUD
was $499.00
In Stock with Supplier Usually ships in 2 - 3 working days what does this mean?
SALE
- +
ON SALE in Winter Sale 2025 while stock lasts
Afterpay
Email me when stock arrives
Request price match
Talk to our experts
Shipping & Availability
Usually ships in 2 - 3 working days. Deliver to New South Wales for $5.90 Change location
Click & Collect Availability
Sydney Out of stock. Pickup in 3 - 4 working days
Click & Collect

Related Products

Sale
Blackmagic Micro BNC to BNC Male Cable (0.7m)
Blackmagic Micro BNC to BNC Male Cable (0.7m)
$63.95 $65
In Stock with Supplier Usually ships in 2 - 3 working days

Features

  • 1920 x 1080 Touchscreen LCD
  • Records 1080p up to 60 fps
  • 10-Bit, 4:2:2 ProRes & DNxHD Encoding
  • HDMI and 6G-SDI Video Inputs
  • Loop-Through Video Outputs

Description

The Blackmagic Video Assist 5” 3G is a portable monitor, a professional recorder, a portable scope and a fantastic camera viewfinder solution! You can also add better quality record codecs and a larger monitor to any SDI or HDMI camera! The new design has innovations such as 4 built in scopes, enhanced focus assist features, a tally indicator and built in 3D LUTs. The Video Assist 5” 3G support formats up to 1080p60 and the new design also has L-Series batteries for longer life. Blackmagic Video Assist 5” 3G really is 4 products in one!

Key Features
  • 1920 x 1080 Touchscreen LCD
  • Records 1080p up to 60 fps
  • 10-Bit, 4:2:2 ProRes & DNxHD Encoding
  • HDMI and 6G-SDI Video Inputs
  • Loop-Through Video Outputs

Specifications
Display
Type LCD touchscreen
Size 12.7 cm
Resolution 1920 x 1080
Viewing Angle 135°
Connections
SDI Video Input 1 x Micro BNC
SDI Video Output 1 x Micro BNC
HDMI Video Input 1 x HDMI Type A
HDMI Video Output 1 x HDMI Type A
SDI Audio Input 16 channels embedded via SDI
SDI Audio Output 16 channels embedded via SDI
HDMI Audio Input 8 channels embedded
HDMI Audio Output 8 channels embedded
Audio Output 1 x 3.5 mm stereo analogue audio output jack
USB Interface 1 x USB 2.0 (Mini-B connector)
Recording
Recording Media UHS-1 SDHC/SDXC cards
Codecs Supported Apple ProRes 422 HQ, 422, LT, Proxy
Avid DNxHD 220x, DNxHD 145, DNxHD 45, DNxHD 220x MXF, DNxHD 145 MXF, DNxHD 45 MXF
Supported Video Formats SDI:
1920 x 1080p 23.98/24/25/29.97/30/50/59.94/60
1920 x 1080PsF 23.98/24
1920 x 1080i 50/59.94/60
1280 x 720p 50/59.94/60
625/50i PAL
525/59.94i NTSC

HDMI:
1920 x 1080p 23.98/24/25/29.97/30/50/59.94/60
1920 x 1080i 50/59.94/60
1280 x 720p 50/59.94/60
480p60
576p50
625/25 PAL
525/29.97 NTSC
Recording Time With 128GB SD card:

Apple ProRes 422 HQ: 1.61 hours
ProRes 422: 2.43 hours
ProRes LT: 3.47 hours
ProRes Proxy: 7.9 hours
SDI Video Sampling 4:2:2 YUV
SDI Audio Sampling 48 kHz, 24-bit
SDI Colour Precision 10-bit
SDI Compliance SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 425M
SDI Metadata Support HD RP188 and closed captioning
SDI Colour Space REC 601, REC 709
HDMI Colour Precision 10-bit
HDCP Compatible No
General
OS Compatibility Mac OS X 10.9 Mavericks
Mac OS X 10.10 Yosemite or later
Windows 7
Windows 8
Power Requirements 12 VDC - DC Input can operate on a voltage tolerance between 10.8 volts to 17 volts.
Batteries 2 x L-Series batteries
AC Adapter 110 to 240 VAC
Operating Temperature 5 to 40°C
Storage Temperature -21 to 45°C
Relative Humidity 0 to 90% non-condensing
Dimensions 14.30 x 3.05 x 8.99 cm
Weight 362.02 g

In The Box

  • Blackmagic Design Video Assist
  • 12V Universal Power Supply with International Socket Adapters

Reviews

5.0 (based on 1 rating)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review

Details

  • Product: Blackmagic Video Assist 3G 5" Portable Monitor
  • Manufacturer: Blackmagic
  • Model: BMD-HYPERD/AVIDA03/5
  • SKU: BMD-HYPERD/AVIDA03/5
  • RM Product #: 74441
  • Screen Size: 5"
  • Screen Resolution: 1920 x 1080
