| Imaging |
|
|
| Number of Cameras |
1 |
|
| Camera System |
1/1.3" CMOS Sensor, 48MP Effective Pixels |
|
| Zoom |
4K: 1 to 3x
FHD: 1 to 4x
2.7K Vertical: 1 to 3x
Photo: 1 to 3x |
|
| Minimum Focus Distance |
1 m |
|
| ISO Sensitivity Range |
Video Normal: 100 to 12800
Video D-Log M: 100 to 3200
Slow Motion Normal: 100 to 6400
Photo: 100 to 6400 at 12MP, 100 to 3200 at 48MP |
|
| Shutter Speed |
12MP Photo: 1/10000 to 2 Seconds
48MP Photo: 1/16000 to 2 Seconds |
|
| Maximum Video Resolution |
4K: 3840 x 2160 up to 100fps
FHD: 1920 x 1080 up to 200fps
2.7K Vertical: 1512 x 2688 up to 60fps |
|
| Still Image Support |
JPEG / DNG RAW, up to 8064 x 6048 |
|
| Photo Modes |
Single Shot, Burst Shooting, Auto-Exposure Bracketing, Timed |
|
| Colour Mode |
Normal 8-Bit or 10-Bit, D-Log M 10-Bit |
|
| Media/Memory Card Slot |
1x microSD/microSDHC/microSDXC, A2 V30 or Faster Recommended |
|
| Internal Storage |
42GB |
|
| Performance |
|
|
| Maximum Horizontal Speed |
18 m/s in Sport Mode, 12 m/s in Normal Mode |
|
| Maximum Tracking Speed |
12 m/s |
|
| Maximum Ascent Speed |
7 m/s in Sport Mode, 5 m/s in Normal Mode, 3 m/s in Cine Mode |
|
| Maximum Descent Speed |
7 m/s in Sport Mode, 5 m/s in Normal Mode, 3 m/s in Cine Mode |
|
| Maximum Wind Resistance |
10.7 m/s |
|
| Maximum Take-Off Altitude |
4500 m |
|
| Maximum Flight Time |
36 Minutes |
|
| Maximum Flight Distance |
21 km |
|
| Maximum Tilt Angle |
35° |
|
| Hovering Accuracy |
Vertical: ±0.1 m with Vision Positioning, ±0.5 m with Satellite Positioning
Horizontal: ±0.3 m with Vision Positioning, ±1.5 m with Satellite Positioning |
|
| Aircraft |
|
|
| Rotor Configuration |
Quadcopter |
|
| Remote ID |
Not Specified |
|
| Aircraft I/O |
USB-C |
|
| Operating Conditions |
-10° to 40° C |
|
| Class |
C0/C1 (EU) |
|
| Gimbal |
|
|
| Number of Axes |
Three: Pitch (Tilt) / Roll / Yaw (Pan) |
|
| Rotation Range |
Mechanical Range:
Tilt: -126° to 67°
Roll: -49° to 49°
Pan: -30° to 30°
Controllable Tilt Range:
-90° to 40° |
|
| Follow Speed |
100°/s |
|
| Stabilization Accuracy |
±0.01° |
|
| Avoidance/Sensing System |
|
|
| Sensing System |
Omnidirectional Monocular Vision System with Forward-Facing LiDAR and Downward Infrared Sensor |
|
| Sensing System Capabilities |
Forward: 0.5 to 20 m Detection Range, Effective up to 12 m/s
Backward/Lateral: 0.5 to 15 m Detection Range, Effective up to 8 m/s
Upward/Downward: 0.5 to 15 m Detection Range, Effective up to 5 m/s |
|
| Forward-Facing LiDAR |
0.5 to 36 m Measurement Range |
|
| Downward Infrared Sensor |
0.3 to 8 m Measurement Range |
|
| Operating Environment |
Surfaces with Discernible Patterns and Adequate Lighting Above 5 Lux |
|
| Remote Controller / Transmitter |
|
|
| Included Controller |
DJI RC-N3 Remote Controller |
|
| Control Method |
Included Transmitter with Smartphone/Mobile Device |
|
| Transmission System |
DJI O4 |
|
| Maximum Operating Distance |
15 km |
|
| Live View Quality |
Up to 1080p/60fps |
|
| Maximum Download Speed |
O4: 10 MB/s
Wi-Fi 6: Up to 50 MB/s |
|
| Battery Type |
Built-In Lithiu |
m-Ion, 2600 mAh |
| Maximum Operating Time |
3.5 Hours without Charging Mobile Device
1.5 Hours when Charging Mobile Device |
|
| Mobile Device Compatibility |
Devices up to 180 x 86 x 10 mm |
|
| Mobile App Compatible |
Yes: Android & iOS
App Name: DJI Fly |
|
| Charging Input |
5 V, 2 A |
|
| Charging Time |
Approx. 2 Hours |
|
| Dimensions |
104.2 x 150 x 45.2 mm |
|
| Weight |
Approx. 320 g |
|
| Flight Battery |
|
|
| Battery Chemistry |
Lithium-Ion |
|
| Chemical System |
LiNiMnCoO2 |
|
| Battery Capacity |
2788 mAh / 19.52 Wh |
|
| Battery Configuration |
7 V |
|
| Maximum Charging Voltage |
8.6 V |
|
| Charging Temperature |
5° to 40° C |
|
| Weight |
Approx. 74 g |
|
| General |
|
|
| GNSS Support |
GPS, Galileo, BeiDou |
|
| Overall Dimensions |
144 x 94 x 62 mm Folded without Propellers
183 x 251 x 79 mm Unfolded without Propellers |
|
| Weight |
Approx. 249 g Standard Takeoff Weight
Approx. 340 g Maximum Takeoff Weight |
|
