| Display |
|
| Technology |
DLP® |
| Resolution |
1080p Full HD (1920x1080) |
| Brightness |
5,500 Lumens |
| Contrast ratio |
300,000:1 |
| Contrast ratio (Dynamic) |
2,000,000:1 |
| Native aspect ratio |
16:9 |
| Aspect ratio - compatible |
4:3, 16:9, 16:10, Full, Squeeze, Native |
| Keystone correction - horizontal |
+/-30° |
| Keystone correction - vertical |
+/-30° |
| Horizontal scan rate |
15~135 KHz |
| Vertical scan rate |
24~120 Hz |
| Uniformity |
75% |
| Screen size |
30"~306" |
| Light source |
|
| Light source type |
Laser |
| Light source life |
30,000 hours (Eco mode) |
| Optical |
|
| Throw ratio |
1.13:1 ~ 1.47:1 |
| Projection distance |
1m~ 10m (mechanism travel) ;1.3m to 3m (Optical travel) |
| Zoom |
1.3 |
| Zoom type |
Manual |
| Focal length |
16.90mm~21.60mm |
| Native offset |
116% +/-5% |
| Connectivity |
|
| Connections- Inputs |
HDMI 2.0 x2, VGA In x1, Audio 3.5mm x1 |
| Connections - Outputs |
USB-A 2.0 x2, 3D sync out x1, Audio 3.5mm x1 |
| Connections - Control |
RJ45 x1, RS232 x1, 12V trigger x1 |
| Networking |
|
| LAN control |
Yes |
| 24/7 operation |
Yes |
| 360° operation |
Yes |
| Power |
|
| Power supply |
AC 100 ~ 240 V, 50 ~ 60 Hz |
| Power consumption (standby) |
≤0.5 W |
| Power consumption (eco mode) |
150 W@110VAC
147 W@220VAC |
| Power consumption (bright mode) |
210 W @110VAC
205 W @220VAC |
| General |
|
| Noise level (min) |
29 dB(A) |
| Noise level (max) |
29 dB(A) |
| Security |
Security bar, Kensington Lock, Password protected interface |
| Remote control |
Business remote control |
| Speaker count & Watts per speaker |
1 x 15W |
| OSD / display languages |
27 languages: Arabic, Czech, Danish, Dutch, English, Farsi, Finnish, French, German, Greek, Hungarian, Indonesian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Simplified Chinese, Spanish, Swedish, Thai, Traditional Chinese, Turkish, Vietnamese |
| 24/7 operation |
Yes |
| 360° operation |
Yes |
| PC compatibility |
VGA,SVGA,XGA,720p,WXGA,SXGA,SXGA+,UXGA,1080p,WUXGA |
| 2D compatibility |
NTSC,PAL,SECAM,SDTV,HDTV,UHD |
| 3D compatibility |
Supports all HDMI 1.4a mandatory 3D formats (Frame pack, side-by-side, top-bottom) and up converts frame rate from 60Hz to 120Hz or 24Hz to 144Hz |
| Operating conditions |
Max Temperature(operating): 0 ~ 40°C; Tolerance +/- 2°C,
Max Altitude(operating): 10,000 ft., for 0°C~30°C,
Max humidity(operating): 80% RH, non-condensing |
| Input lag |
4K/ 60Hz: 16.7 ms
1080P/ 60Hz: 16.7 ms
1080P/ 120Hz: 8.6 ms |
| Dimensions (W x D x H) |
W/o feet: 216 x 274 x 108.5mm (10.8 x 8.5 x 4.3 inches)
With feet: 216 x 274 x 114mm (10.8 x 8.5 x 4.5 inches) |
| Gross weight |
4.3 kg / 9.5 lbs |
| Net weight |
2.9 Kg / 6.4 lbs |
