The Parallel Audio PERFORMER-L Wireless Lapel System offers a range of impressive features and capabilities. With 100 factory preset UHF frequencies, users have a wide range of options to choose from. The system utilizes advanced microprocessor control and reliable RF design, ensuring excellent signal performance and interference-free multi-channel operation. The patented IrDA technology enables seamless 2-way sync between the transmitter and receiver. Additionally, the system includes a convenient SCAN function that automatically locates the next clean frequency. Thanks to its diversity design, the system provides high sensitivity, selectivity, and rejection of spurious signals. The receiver features an LCD display for easy frequency selection, and antennas can be mounted either in the rear or front. With anti-interference Pilotone control and RF noise squelch circuitries, the system delivers clear and reliable audio quality. RF and AF LED indicators provide visual feedback on signal strength. The system also includes balanced (XLR) and unbalanced (O6.3mm) audio outputs for versatile connectivity options. Its half-rack metal chassis is mountable with optional mount kits (such as PA-WRK-1 for 1 unit or PA-WRK-2 for 2 units). Compatible transmitters are HH6100 and BP6100. Furthermore, the system utilizes true diversity reception, ensuring the best performance and reliability. The receiver can also supply power to Parallel Audio antenna systems, further enhancing reception range and signal stability for optimal audio transmission.
Parallel Audio PERFORMER-L Wireless Lapel System
Usually ships in 1 - 2 weeks
Our Price
$689
AUD
Usually ships in 1 - 2 weeks
Email me when stock arrives
Shipping & Availability
Usually ships in 1 - 2 weeks.
Deliver to
New South Wales
for $5.90
Change location
Click & Collect Availability
Sydney
Out of stock.
Pickup in
1 - 2 weeks
Click & Collect
Features
- 100 factory preset UHF frequencies
- Advanced microprocessor control
- Patented IrDA technology
- SCAN function
- Diversity design
- LCD display on receiver
Description
Specifications
| Channel | Single |
| Chassis | EIA standard 19" 1/2U |
| Frequency range | UHF 520-675MHz (3 available bands) |
| Bandwidth | Up to 25MHz |
| Receiving mode | True Diversity |
| Peak deviation | ñ40kHz |
| Channel sync | 2-way (receiver - transmitter) |
| Sensitivity | S/N > 80dBm at 10dB?¬V |
| S/N ratio | > 110dB (A) |
| T.H.D. | < 0.5% @ 1kHz |
| Frequency response | 50Hz - 18kHz |
| Receiving antenna | Rear Panel. Detachable |
| Preset channels | 100 |
| Oscillation mode | PLL synthesised, frequency stability ??ñ 0.005% (-10 - +60C) |
| Squelch | Pilotone & Noise-cancelling dual-squelch circuit |
| Audio output adjustment | Gain control circuit for adjustment of output volume |
| Output connector | Balanced XLR and unbalanced 6.3?? |
| Power supply | 12V DC, 1.0A |
| Power consumption | 12W |
| Dimensions (mm) | 200 (W) x 44 (H) x 150 (D) |
| Weight (kg) | 0.63 |
In The Box
- Performer-100 Wireless Receiver
- BP6100 Beltpack Transmitter
- LP-16L Lapel Mic
Reviews
(no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: Parallel Audio PERFORMER-L Wireless Lapel System
- Manufacturer: Parallel Audio
- Model: PERFORMER-L
- SKU: PERFORMER-L
- RM Product #: 116953
- System Type: Lapel System
