Sachtler System 20 S1 HD CF
Features
- Video 20 S1 Fluid Head
- ENG 2 CF HD Tripod
- Ground-level Spreader
- Padded Bag
- 16-step Counterbalance
Related Products
Description
The Sachtler System 20 S1 HD CF brings together the update of a classic fluid head with a quick-action, double extension tripod to provide a professional level of support for today's news-gathering videographer. Whether you're shooting with a large ENG camcorder or the latest video DSLR, this system--which also includes ground spreaders and a padded carry bag--will give you the quick, easy balance and flexible control you need.
Features
Video 20 S1 Fluid Head
This relaunch of the legendary Video 20 head incorporates a wider payload range and a faster, simpler balancing system. The increased range means that even lightweight cameras--such as video DSLRs--can be used effectively, aided by a 16-step counterbalance system that allows for fine degrees of tuning. Like its predecessor, the Video 20 S1 can also easily handle heavier ENG and EFP camcorders, with a Boost Button included for sudden shifts in payload range. Other features include 7 levels of drag, a self-illuminating bubble level, a Touch and Go plate for speedy mounting and removal, and Sachtler's already proven Speedbalance technology.
ENG 2 CF HD Tripod
The ENG 2 CF is extremely lightweight, solid and stable. Weighing in at just 4kg, its completely dual tube design ensures it can safely carry payloads of up to 95kg even at its maximum height. Double extension tripods are ideal for a much wider variety of applications, due to their expanded height range--i.e., lower bottom and higher top positions--which makes transport length even shorter. A folding handle lets you easily carry the tripod in a horizontal position, while Sachtler's quick clamping system means you can securely--and visibly--lock the tripod.
Ground-level Spreader, Carry Bag
The included ground-level spreader ensures absolute stability on flat surfaces, while the ENG/EFP padded bag comfortably and quickly contains the whole kit for efficient transport.
Specifications
General | |
Load Capacity | 2-25kg |
Maximum Height | 70.1" (178cm) |
Minimum Height | 28.3" (72cm) |
Folded Length | 37" (94cm) |
Levelling Bubble/Illuminated | Yes/Yes |
Weight | 10.4kg |
Head | |
Counter Balance System | 16 Steps + Boost Button |
Quick Release/Wedge Plate | Touch & Go Plate 16 |
Balance Plate | 4.7" (120mm) |
Tilt Drag | 7 Steps |
Tilt Range | +90° to -70° |
Tilt Lock | Independent |
Spring Loaded Counter Balance | 7 Steps |
Pan Range | 360° |
Pan Lock | Independent |
Legs | |
Material | Carbon Fibre |
Head Attachment Fitting | 100mm |
Leg Stages/Sections | 2/3 |
Leg Lock Type | Quick Clamp Torque Lock |
Independent Leg Spread | Yes |
Spiked/Retractable Feet | Spiked |
Centre Brace | Ground-level |
In The Box
- Sachtler System 20 S1 HD CF
- Video 20 S1 Fluid Head
- Telescoping Pan Bar
- ENG 2 CF HD Tripod
- Ground-level Spreader
- Padded Bag
- Limited 1-Year Warranty
Reviews
(no ratings yet)Give it a quick rating:
Thanks for your rating!
Write a review
Details
- Product: Sachtler System 20 S1 HD CF
- Manufacturer: Sachtler
- Model: 2072S1
- SKU: 2072S1
- RM Product #: 652
- Closed Length: 94 cm
- Minimum Height: 72.0 cm
- Load Capacity: 25.0 kg
- Weight: 10.40 kg
- Maximum Height: 178.0 cm
- Head Type: Fluid
- Material: Carbon Fibre
- Stage & Sections: 2/3
