| System |
|
| Wireless Technology |
Digital 2.4 GHz/5.8 GHz |
| Included Transmitters |
1 x Bodypack |
| Diversity |
True Digital Diversity |
| RF Channel Scanning |
Auto-Scan |
| Max Operating Range |
30.5 m (Line of Sight) |
| Max Transmitters per Band |
8 |
| Built-In Recorder |
No |
| Timecode Support |
No |
| Mobile App Compatible |
No
*As of February, 2023: Cheque with manufacturer for the most up-to-date compatibility |
| Dynamic Range |
120 dBA |
| Modulation |
Proprietary |
| Receiver |
|
| Receiver Type |
Tabletop |
| Antenna |
2 x 1/2 Wave Sleeve Dipole, Fixed (Front-Mount) |
| Number of Audio Channels |
1 |
| Audio I/O |
1 x XLR 3-Pin Male Balanced Mic/Line Output
1 x 1/4" TRS Female Balanced/Unbalanced Output |
| Gain Range |
-20 to +40 dB (1 dB Steps) |
| Audio Output Level |
XLR Output:
+1 dBV
1/4" Output:
+8.5 dBV |
| Phantom Power Protection |
On 1/4", XLR Outputs |
| Frequency Response |
20 Hz to 20 kHz (Dependant on Mic) |
| Network I/O |
None |
| Word Clock I/O |
None |
| USB/Lightning Connectivity |
1 x USB-C Female (Firmware Update) |
| Impedance |
XLR Output:
100 Ohms (Balanced)
1/4" Output:
100 Ohms (Balanced)
50 Ohms (Unbalanced) |
| RF Output Power |
10 mW (EIRP, Max) |
| Spurious |
Rejection: >35 dB |
| Power Requirements |
AC/DC Power Adapter |
| AC/DC Power Adapter |
14.5 to 17 VDC at 600 mA (Included) |
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz |
| Display & Indicators |
1 x Backlit LCD (AF Level, Channel, Frequency, Group, Transmitter Battery Status) |
| Housing |
ABS |
| Operating Temperature |
0 to 45°C |
| Dimensions |
.183 x 40 x 122 mm |
| Weight |
310 g |
| Transmitter |
|
| Transmitter Type |
Bodypack |
| RF Output Power |
10 mW (EIRP) |
| Audio I/O |
1 x TA4/Mini XLR 4-Pin Male Unbalanced Input (Lockable) |
| Plug-In Power |
5 V |
| Pad |
None |
| Muting |
Off/On Switch |
| Audio Input Level |
-8.4 dBV / 7.5 V p-p |
| Auto-Level Control |
No |
| Gain Range |
-18 to +42 dB (1 dB Steps) |
| Sync Method |
Proprietary |
| Antenna |
1 x Internal, Fixed (Beltpack) |
| Power Requirements |
Battery |
| Battery Type |
1 x Shure SB904 (Included, Replaceable) |
| Internal Battery Capacity |
2420 mAh |
| Battery Charging Time |
.25 to 3 Hours |
| Approx. Battery Life |
12 Hours (Lithium Rechargeable) |
| USB/Lightning I/O |
1 x USB-C (Charging) |
| Display & Indicators |
1 x LED (Battery Status, Sync) |
| Housing |
Metal |
| Dimensions |
67 x 115 x 28.5 mm (without Antennas) |
| Weight |
5.4 oz / 153.1 g (without Batteries) |
| Microphone |
|
| Microphone Type |
Headset |
| Colour |
Black |
| Sound Field |
Mono |
| Capsule |
Electret Condenser |
| Polar Pattern |
Cardioid, Unidirectional |
| Frequency Range |
60 Hz to 20 kHz |
| SNR |
66 dB |
| Equivalent Noise Level |
28 dB A-Weighted |
| Maximum SPL |
145 dB SPL |
| THD |
< 3% |
| Impedance |
600 Ohms |
| Dynamic Range |
117 dB |
| Outputs |
1 x TA4/Mini XLR 4-Pin Female Unbalanced (Lockable) |
| Cable Length |
4.3' / 1.3 m |
| Operating Voltage |
5 to 10 V |
| Operating Current Consumption |
40 µA |
| Weight |
45 g |
