StarTech Triple Head Mini DisplayPort 1.2 to 3 x DisplayPort Hub

Product #80222 | SKU MSTMDP123DP | Startech
In Stock with Supplier Usually ships in 3 - 4 working days what does this mean?
Not currently for sale
Contact us for more information
In Stock with Supplier Usually ships in 3 - 4 working days what does this mean?

Features

  • Increase your productivity
  • Triple monitor adapter
  • MST technology t
  • Built-in 1' cable

Related Products


Description

This StarTech Triple Head Mini DisplayPort 1.2 to 3 x DisplayPort Hub lets you connect three DisplayPort monitors to your Mini DisplayPort computer. MST works on any Windows® device that supports DisplayPort 1.2, such as models of the Lenovo™ Think Pad® and Microsoft® Surface™. When connected to earlier revisions of DisplayPort, such as DP 1.1 the MST hub acts as a video splitter.

Key Features:

Increase your productivity with multiple monitors

The newest generations of laptops are more portable than ever, unfortunately this means you’re left with fewer video outputs and a small integrated screen. The MST hub solves these problems by letting you connect three independent displays to a single mDP port on your computer, which makes multitasking much easier. Using the MST hub, you can extend your desktop onto additional monitors and stream independent content to each display, which makes it easier to multitask and increase your productivity - perfect for creating an easy-to-dock hot desk solution with a wireless keyboard and mouse peripheral set. You can also mirror the same image onto multiple displays for remote viewing applications such as digital signage.

Astonishing picture quality that won’t drain your system resources

MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. 4K is supported by the latest A/V devices and delivers four times the resolution of 1080p. Plus, because the MST hub can output high-definition 1080p, the MST hub is perfect for all high-resolution applications such as graphic design and medical imaging.

Works with any monitor, television or projector

With this MST hub, you can use separate mDP video adapters to connect HDMI, VGA or DVI displays, for compatibility with all of your existing monitors. The hub is VESA and DisplayPort certified to support DP 1.2 enabled systems, for seamless integration with your existing video equipment.

Specifications

Connector
1 - Connector A Mini-DisplayPort (20 pin)
3 - Connector B DisplayPort (20 pin)
Environmental
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Hardware
Active or Passive Adapter Active
AV Input Mini DisplayPort - 1.2
Ports 3
AV Output DisplayPort - 1.2
Audio Yes
Chipset ID MegaChips - STDP4320
Packaging Information
Package Height 180,4 ft [55 m]
Package Length 508,4 ft [155 m]
Shipping (Package) Weight 899,5 lb [407 kg]
Package Width 747,8 ft [228 m]
Performance
Audio Specifications DisplayPort - 5.1 Channel Audio
Maximum Cable Distance To Display 6,6 ft [2 m]
Maximum Digital Resolutions Up to 4K
Supported Resolutions Average resolution bandwidth allocation
1920x1080 (High-definition 1080p) @60hz - 22%
1920x1200 @60hz - 30%
2560x1440 @60hz - 35%
2560x1600 @60hz - 38%
3840 x 2160 (Ultra HD 4K) @30hz - 38%
Note: Exceeding 100% will reduce functionality.
Wide Screen Supported Yes
Physical Characteristics
Weight of Product 192,3 lb [87 kg]
Color Black
Material Plastic
Cable Length 7,5 in [19 cm]
Product Length 656,0 ft [200 m]
Product Width 255,8 ft [78 m]
Product Height 65,6 ft [20 m]
Power
Power Source AC Adapter Included
Input Voltage 100 - 240 AC
Input Current 0.5 A
Output Voltage 5 DC
Output Current 3A
Center Tip Polarity Positive
Plug Type N
Power Consumption (In Watts) 15

In The Box

  • Mini DisplayPort to DisplayPort MST Hub
  • Universal Power Adapter (NA/EU/UK/AUS)
  • Instruction Manual

Reviews

0.0 (no ratings yet)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review

Details

  • Product: StarTech Triple Head Mini DisplayPort 1.2 to 3 x DisplayPort Hub
  • Manufacturer: Startech
  • Model: MSTMDP123DP
  • SKU: MSTMDP123DP
  • RM Product #: 80222
