Yamaha HS4 Active 4.5" 2-Way Studio Monitors (Black)
Features
- For Music Production and Video Editing
- 1" Dome Tweeter and 4.5" Cone Woofer
- 26W Output Power per Speaker
- 3-Way 500 Hz Room Control Switch
- 3-Way 2 kHz HF Trim Switch
- Wide Frequency Response
Description
The Yamaha HS4 Active 4.5" 2-Way Studio Monitors are a compact version of the highly regarded HS series speakers. These two 2-way nearfield monitors offer a wide and accurate frequency response, making them ideal for music production and video editing in limited spaces. The HS4 features a 1" dome tweeter, a 4.5" cone woofer, and a 26W amplifier. Its rear panel includes 3-way room correction trim switches for adjusting low and high frequencies, while the front panel has volume control. The monitors provide various connection options, including XLR-1/4" combo, stereo 3.5mm, and stereo RCA inputs. Additionally, there is a headphone output for easy switching between monitors and headphones. The package includes a speaker cable, a stereo 3.5mm to RCA cable, and eight antislip pads.
Specifications
Key Specs | |
Monitor Type & Configuration | Active 2-Way |
Total Power Output | 26 W per Monitor |
Tweeter | 1 x 1" / 25.4 mm Dome |
Woofer | 1 x 4.5" / 11.4 cm Cone |
Frequency Range | 83 Hz to 20 kHz (-3 dB) 60 Hz to 22 kHz (-10 dB) |
Audio I/O | 2 x Combo XLR-1/4" TRS Balanced Mic/Line Input (20 Kilohms) 1 x 1/8" / 3.5 mm TRS Unbalanced Line Input (10 Kilohms) 1 x Stereo 2RCA Unbalanced Line Input (10 Kilohms) 1 x 1/8" / 3.5 mm TRS Speaker Input 1 x 1/8" / 3.5 mm TRS Headphone Output 1 x Binding Post Pair Speaker Output |
Digital Audio I/O | No |
Network I/O | No |
Wireless | No |
Number of Included Monitors | Stereo Pair |
Enclosure | Bass-Reflex/Ported |
Total Power Output | 26 W per Monitor |
Drivers per Monitor | |
Tweeter | 1 x 1" / 25.4 mm Dome |
Woofer | 1 x 4.5" / 11.4 cm Cone |
Amplifiers | Full-Range: 26 W Class-D |
Performance | |
Frequency Range | 83 Hz to 20 kHz (-3 dB) 60 Hz to 22 kHz (-10 dB) |
Maximum Sound Pressure Level (SPL) | 102 dB (Peak) |
Maximum Input Level | +20 dBu (Balanced) +6 dBu (Unbalanced) |
Signal Processing | |
AEQ | 1 x LF Shelf: 0 to +4 dB at 500 Hz (2 dB Increments) 1 x HF Shelf: 2 to -2 dB at 2 kHz (2 dB Increments) |
Filters | No |
Parametric AEQ | No |
Crossover Frequency | 2.3 kHz |
Phase Adjustment | No |
Connectivity | |
Audio I/O | 2 x Combo XLR-1/4" TRS Balanced Mic/Line Input (20 Kilohms) 1 x 1/8" / 3.5 mm TRS Unbalanced Line Input (10 Kilohms) 1 x Stereo 2RCA Unbalanced Line Input (10 Kilohms) 1 x 1/8" / 3.5 mm TRS Speaker Input 1 x 1/8" / 3.5 mm TRS Headphone Output 1 x Binding Post Pair Speaker Output |
Digital Audio I/O | No |
Network I/O | No |
USB | No |
Wireless | No |
Mobile App Compatible | No |
Power | |
AC Input Power | 100 to 240 VAC, 50/60 Hz |
Power Consumption | 15 W |
Physical | |
Colour | Black |
Orientation | Vertical |
Enclosure Material | MDF |
Dimensions (W x H x D) | 5.9 x 9.4 x 8.4" / 15 x 23.9 x 21.3 cm (with Amplifier) 5.2 x 8.8 x 7" / 13.2 x 22.4 x 17.8 cm (without Amplifier) |
Weight | 8.2 lb / 3.7 kg (with Amplifier) 6.8 lb / 3.1 kg (without Amplifier) |
In The Box
- Yamaha HS4 Active 4.5" 2-Way Studio Monitors (Black)
- Stereo 3.5mm to RCA Cable
- Speaker Cable
- Anti-Slip Pad
