Zoom H5 Handy Recorder

Product #17453 | SKU H5 | Zoom
In stock Ships Tuesday
Our Price $329.00 AUD
In stock Ships Tuesday
- +

Shipping & Availability
Ships Tuesday. Deliver to New South Wales for $29.38 Change location
Click & Collect Availability
Sydney Out of stock. Pickup in 1 - 2 weeks
Click & Collect

Buy Together & Save!
Zoom H5 Handy Recorder
Zoom H5 Handy Recorder
In stock Ships Tuesday
Zoom EXH-6 Dual XLR/TRS Combo Input Capsule for H6 & H5 Recorder
In stock Ships Tuesday
Buy Together: $406.64

Overview

4 track recorder with interchangeable, modular microphone system

Related Products


Description

The H5 Handy from Zoom is a compact, portable handheld digital recorder that is capable of four-track recording and features an interchangeable, modular microphone system. The recorder ships with an XY microphone capsule and is compatible with the existing line of H6 modules including the optional shotgun mic and XLR/TRS input modules.

The included XY stereo mic module provides two matched unidirectional condenser microphones set at a 90 degree angle, and features a built-in shockmount system and a maximum SPL of 140dB. Additionally, the recorder is equipped with two inputs for external sources, allowing you to record simultaneously with the included stereo XY mic for a total of four input channels. Each input is controllable by its own analogue gain knob, and also has a -20dB pad.

The recorder also has an LCD screen and a side-mounted toggle control for navigating through the menu options. It gives you fast access to transport functions, offering physical control buttons right underneath the screen, and conveniently stores its recorded audio to external SD cards.

In addition to the detachable X/Y capsule, the recorder also ships with a foam windscreen, two AA batteries, a USB cable, WaveLab LE (download), Cubase LE (download), and a hard plastic case.

Features

  • Includes detachable X/Y capsule (XYH-5) with extended signal capacity and shockmounted microphones for reduced handling noise
  • Compatible with Zoom H6 input capsules and optional capsules including the SGH-6 shotgun mic capsule and the EXH-6 dual XLR/TRS combo input capsule
  • Four-track simultaneous recording
  • Large backlit LCD display
  • Records directly to SD and SDHC cards up to 32GB
  • Up to 24-bit/96kHz audio in BWF-compliant WAV or a variety of MP3 formats
  • Two mic/line inputs with XLR/TRS combo connectors, each with selectable phantom power and -20dB pad
  • Analogue-style gain controls for each input
  • Protective "roll-bar" type covers prevent accidental movement of gain controls
  • Plug-in power (2.5 volts)
  • Built-in effects, including low-cut filtering, compression and limiting
  • Chromatic tuner and metronome
  • Auto-record, Pre-record and Backup-record functions mean that you'll never miss that perfect take
  • MS decoding
  • Multitrack to stereo internal mixdown
  • Normalise, Divide and Trim editing
  • Voice memo and up to 99 marks per recording
  • A/B loop playback
  • Variable playback speed and variable pitch without affecting playback speed
  • Multichannel and stereo USB audio interface for PC/Mac/iPad with loop back function
  • Mountable to DSLR or camcorder with optional HS-01 Hot Shoe Mount adapter
  • Uses two standard AA alkaline or NiMH rechargeable batteries
  • Over 15 hours of operation with alkaline batteries

Specifications

General
Recording Media SD card: 16MB to 2GB
SDHC card: 4GB to 32GB
Display Backlit LCD (128 x 64 pixels)
Power Requirements AA size (LR6) battery x 2
AC adapter (AD-17 (DC5V/1A/USB-type, optional)
USB bus power
I/O
Inputs L/R [XYH-5 X/Y mic]:
Mic Type: Unidirectional
Sensitivity: -45 dB, 1 kHz at 1 Pa
Input Gain: -∞ to 52 dB
Max Sound Pressure Input: 140 dB SPL

Mic/Line In:
Connector: 1/8" stereo mini jack
Input Gain: -∞ to 52 dB
Input Impedance: 2 kΩ or more
Plug-In Power: 2.5V supported
Backup Recording: -12 dB lower than set L/R input gain

Inputs 1/2:
Connectors: XLR / TRS combo jacks (XLR: Pin 2 hot / TRS: Tip hot)
Input Gain (PAD OFF): -∞ to 55.0 dB
Input Gain (PAD ON): -∞ to 35.0 dB
Input Impedance: 1.8 kΩ or more
Max Input Level: +22 dBu (PAD ON)
Phantom Power: +12V /+24V /+48V
Equivalent Input Noise (EIN): -120 dBu or less
Outputs Line Out:
Connector: 1/8" stereo mini jack
Rated Output Level: -10 dBm
Output Load Impedance: 10 kΩ or more

Phone Out:
Connector: 1/8" stereo mini jack
Output Level: 20 W + 20 W into 32 Ω load

Built-in speaker:
400 mw 8 Ω mono
USB Mass Storage Class Operation:
Class: USB 2.0 high speed


Audio Interface Operation:

Multitrack Mode:
Class: USB 2.0 high speed
Sampling Frequency: 44.1/48 kHz
Bit Rate: 16-/24-bit
Inputs / Outputs: 4 / 2

Stereo Mode:
Class: USB 2.0 full speed
Sampling Frequency: 44.1/48 kHz
Bit Rate: 16-bit
Inputs / Outputs: 2 / 2
USB Bus Powered Operation: Yes
iPad Operation: Supported in stereo mode only
Recording
Recording Formats Stereo Mode:
WAV (BWF-compliant)
Sampling Frequency: 44.1/48/96 kHz
Bit Rate: 16-/24-bit (Stereo)
Maximum Simultaneous Recording Tracks: 2
MP3
Sampling Frequency: 44.1 kHz
Bit Rate: 48/56/64/80/96/112/32/160/192/224/256/320 kbps

Multi-Track Mode:
WAV (BWF-compliant)
Sampling Frequency: 44.1/48 kHz
Bit Rate: 16-/24-bit (mono/stereo)
Maximum Simultaneous Recording Tracks: 6 (L/R + INPUT 1/2 + L/R backup)
Physical Specifications
Dimensions H5: 66.8 x 135.2 x 42.1 mm
XYH-5 X/Y mic: 65.5 x 62.2 x 41 mm
Weight H5: 176.0 g
XYH-5 X/Y mic: 94.0 g

In The Box

  • Zoom H5 Handy Recorder with Interchangeable Microphone System
  • XYH-5 Microphone Capsule
  • Plastic Case
  • Foam Windscreen
  • USB Cable
  • Steinberg WaveLab LE Software (Download)
  • Steinberg Cubase LE Software (Download)
  • Limited 1-Year Warranty

Reviews

4.0 (based on 6 ratings)
Own or use this product?
Give it a quick rating:
Thanks for your rating!
Share your thoughts with other customers:
Write a review
  • Ratu
    The battery life on this Zoom is king. I tested with the provided alkaline batteries using the top mic at 48khz/16bit and I gave up after six hours. There was one bar left. I then used power rex re-charge batteries (not new) and used the top mic, input 1 from an iPad, input 2 to from a sony wireless mic system (phantom off on 1 & 2). Recorded 48khz/16bit. After four hours of recording finally got the unit down to 1 bar. My old Zoom h4n was no where near as good as this battery king. I am more than happy with the battery life on this unit. I've not bothered with the sound quality, I've seen enough reviews on youtube to know its good enough for me. Cheers Ratu
    Read more Read less
  • Simon
    The recorder works as expected. It’s also a bonus that it can take the mic capsules Zoom makes. I find it really useful for recording band practices and similar. Note that Zoom recorder pre-amps have quite a bit of self-noise so they are not so good with recording quiet things. Recommended as a general purpose easy to use recorder.
    Read more Read less
